large led color screen/billboard manufacturer from China Tan Lei

Price:	2000.0 USD
Payment Terms:	T/T,L/C,D/A
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,Land

Production Capacity: 5000sq.m.

Advantages Description
Freely set various dynamic patterns
Two sides display with high brightness
Beautiful appearance
Light weight
Small thickne

Aluminum alloy

Hard, durable and light

New design structure of the screen

Beautiful image

Fluent streak

Ultra thin design

Video fluent

1.Hard, durable and light aluminum alloy. New design structure of the screen with beautiful image and fluent streak. Between the unit curtains is jointed waterproof with neat connection to avoid the chaos connection of the rental screen used outdoor or indoor.

2.Unit curtain can be jointed with number random. Use the software to control all the modules to display one whole.

3.You needn't take the installation tool by yourself then you can install it easily.

4.This product has the brightness adjustment from 500-5500nit at whole day.

5.IP65, it can stand any hard weather and work well outdoor for a long time.

6.60% penetrating makes the screen can withstand the strong wind. Its special design greatly improve the installation and maintenance.

7.Ultra thin design reduces the weight of the screen to the bottom.

8.Point-to-point correct each pixel, module, cabinet and whole screen to be perfect white balance.

9.Use the advanced display technology to reduce the failure and improve the reliability of the system and make the image stable and video fluent.

Type	Outdoor Full Color Display
Best Viewing Distance(m)	129
Pixel Pitch(mm)	37.5
Pixel Density(Dots/sqm)	711
Configuration	1R1G1B(3-in-1 SMD)
Unit Box Pixel(Dots)	24*24
Cabinet Size(WxHxT)	90090060
Cabinet Weight(Kg)	8.5
Brightness(cd/sqm)	1300
Refresh Frame Frequency(Hz)	800
MTBF(H)	10000
Maximum Power Consumption(W/sqm)	250
Average Power Consumption(W/sqm)	125
Left/right Viewing Angle(Degree)	140°
Grey Scale	12bit
Display Color	16777216colors
Brightness Adjust	256 grade automatic,100 grade manual
IP Standard	IP65
Display Module Brightness Uniformity	5%
Pixels Out Of Control Rate(Dots)	1/100000 Dots
Life Span(H)	100000
Operating Voltage	AC220V/50Hz&AC110V/60Hz available
System Working Environment Temperature	–20℃~+60℃
System Working Environment Humidity	10%RH~90%RH
